SC40
40A Amp Plasma Cutter
| Model No. | SC40 |
|---|---|
| Specification | 40A Amp Plasma Cutter |
| Rated Input | AC230V+/- 15% Single phase, 50/60HZ |
| Rated Input Current | 24.3Amp |
| Power Capacitance | 5.6KVA |
| No Load Voltage | 220V |
| Current Range | 20-40Amp |
| Voltage Range | 88-96V |
| Duty Cycle I max (25degC) | 60% |
| Duty Cycle Amp 100%(25degC) | 31A |
| Efficiency | 85% |
| Power Factor | 0.8 |
| Arc Starting | Touch |
| Compressed Air (for Carbon Steel) | 0.4-0.6Mpa,7800L/h |
| Compressed Air (for Stainless Steel) | 0.4-0.6Mpa,1200L/h |
| Maximum Cutting Thickness | 12mm |
| Size | 371x155x295mm |
| Net Weight | 8.6Kg |
