SC160
160A Amp Plasma Cutter
| Model No. | SC160 |
|---|---|
| Specification | 160A Amp Plasma Cutter |
| Rated Input | AC415V+/- 15% Three phase, 50/60HZ |
| Rated Input Current | 41.9Amp |
| Rated Input Capacity | 29KVA |
| Rated Output | 160/144 Amp/V |
| Welding Current Range | 30-160Amp |
| No Load Voltage | 400V |
| Duty Cycle I max (40degC) | 60% |
| Duty Cycle Amp 100%(40degC) | 120A |
| Efficiency | 88% |
| Power Factor | 0.8 |
| Arc Starting | LF/HF |
| Compressed Air (for Carbon Steel) | 0.4-0.6Mpa,7800L/h |
| Compressed Air (for Stainless Steel) | 0.4-0.6Mpa,1200L/h |
| Maximum Cutting Thickness | 60mm |
| Quality Cutting Thickness | 40mm |
| Protection Class | IP21S |
| Insulation Class | F |
| Size | 610x325x575 |
| Net Weight | 46Kg |
